Modern Robotics 12VDC Motor
Modern Robotics 12VDC Motor
5000-0002-0001Preț obișnuit
114,90 lei
Preț redus
114,90 lei
Preț unitar
/
pe
Prețul include taxe.
⚠️ Acest produs este disponibil în regim de precomandă. Timpul estimat de livrare este de 3-12 zile lucrătoare de la confirmarea plății, în funcție de opțiunea aleasă la checkout (Economy, Standard sau Priority).
📦 Costul final de transport poate crește dacă în coș se află produse de la mai mulți furnizori (ex: 2 furnizori = 2 taxe de transport).
📦 Costul final de transport poate crește dacă în coș se află produse de la mai mulți furnizori (ex: 2 furnizori = 2 taxe de transport).
SKU: 5000-0002-0001
Nu am putut încărca disponibilitatea pentru ridicare
This brushed DC motor is legal in FTC (FIRST Tech Challenge). It’s the powerhouse driving the gearboxes of our Yellow Jacket Planetary Gear Motors, and can swap into those motors to perform as a replacement core, if ever required. Its encoder is designed to work at 3.3V or 5V. Whether you are using an Arduino or the REV Expansion Hub, you don't need to bother with a logic level converter.
Downloads
Specs
| Weight | 8.71oz (247g) |
|---|---|
| Motor Type | Brushed DC |
| Nominal Voltage | 12VDC |
| No-Load Speed @ 12VDC (Theoretical) | 6000 RPM |
| No-Load Speed @ 12VDC (Tested) | 5800 RPM |
| Stall Current @12VDC | 9.2A |
| Stall Torque @12VDC | 1.47 kg.cm (20.45 oz-in) |
| Motor Connector Type | 3.5mm FH-MC Bullet Connectors |
| Encoder Connector Type | 4-Pos JST XH [FH-MC] |
| Encoder Type | Relative, Quadrature |
| Encoder Sensor Type | Magnetic (Hall Effect) |
| Encoder Voltage Range | 3.3 - 5VDC |
