Hey, FTC teams, this is for you!
NeveRest Sport planetary gearboxes are created with FIRST Tech Challenge teams in mind. Designed in collaboration with BaneBots, these gearboxes have a Nub-shaped output shaft, and all the mounting features are designed around common FTC hole spacing for maximum compatibility. The shaft and gears are robust, machined steel components designed to withstand many times more power than a NeveRest motor will supply. With seven ratios up to 256:1, you're sure to find a ratio that fits your application.
These gearboxes accept one NeveRest Motor (am-3104), sold separately. We include a packet of Red Tacky Grease (am-2768) with each NeveRest Sport gearbox order; a pea-sized amount on each stage of reduction before running it will ensure smooth, trouble-free operation.
These gearboxes are more expensive and more robust than the small gearboxes usually mounted on the face of NeveRest gearmotors. than what a standard NeveRest gearbox (or its mount) can handle. The NeveRest Sports have a max loading of 6700 oz-in, or 35 ft-lbs.
Mounting Features
- 6-32 tapped holes on two faces, on a 16 mm hole spacing
- 6-32 tapped holes on a 28 mm bolt circle for face mounting, same as our NeveRest Orbital gearmotor.
Output Geometry
- Nub shaped output shaft with 6-32 tapped holes on a 16 mm bolt circle
- 6 mm hole and set screw for any length 6 mm D shaft or 5 mm hex shaft
Gearing
- The 15 tooth pinion and all internal gears are 0.6 module
- All first stage gear sets have 4 planet gears
Included Hardware
- 1 - NeveRest Sport gearbox assembly (depending on which gearbox selected)
- 1 - NeveRest Sport Motor Mounting Kit (am-2890)
